Category Archives: Tugboats for Sale (Model Bow)

1800 HP Tug

Posted on by

90′ x 28′ x 9.5′

(2) Cat 398 @ 900 HP

191/101 G/N Tons

COI and ABS Loadline

Caribbean

$1.95MM

2000 HP Tug w COI

Posted on by

74′ x 26′ x 8.5′

Early 80s Build

(2) 16v149s

7:1 Gears

90GT 60NT

Skagit Single w 150,000 lb. Line Pull

28,000g Fuel 6,000g Water

(2) GM 40kw Gen

Fresh COI 8\22

3600 HP Ocean Tugboat

Posted on by

107′ x 29.9′ x 13.7′

298 GRT 90 NT

2007 Build

Mexican Flagged

2 Cummins 50-M2 Main Engines

52 Ton Bollard Pull

40 Ton Double Drum Tow Winch

GOM

$2.4MM

900 HP Model Bow

Posted on by

49’ x 19’ twin screw model bow

(2) Cummins NTA 855, TD 514 4.5:1- 900hp

Sub M Compliant

New engines, shafts, gears, shaft seals, bearings, elec. Deck winches, galley upgrades.

South East USA

POR

2000 HP Tugboat

Posted on by

Late 1970s Build

72.5′ Length x 24.2′ Beam x 9.5′ Depth x 46.6′ Height

Sub M Compliant No COI

(2) CAT C32 – TIER 2 @ 2000 HP

(2) TWIN DISC 540 @ 5:1

SMATCO DRUM WITH POCKET DRUM / GM 4-71 / 1.5″ x 1,800′

(2) CAT C4.4 Generators

Water 4,000 gals Lube 250 gals Fuel 23,000 gals

East USA

POR

1700 HP Tugboat

Posted on by
  • Late 70s Build
  • 69′ x 26′ x 9.6′
  • Sub M Compliant without COI
  • (2) CAT C32 – TIER 2 1700 HP
  • (2) TWIN DISC MG-5225DC/ 5:1
  • SMATCO DRUM WITH POCKET DRUM / GM 4-71 / 1.5″ x 1,400′
  • Capacities: 7,600 gals water, 300 gals lube 29,500 gals fuel
  • East USA
  • $1,365,000.00

300′ x 90′ ABS Submersible Barge

Posted on by


300′ x 90′ x 22′

Fresh 5 year ABS in 2020

12,231 LT Displacement at LL

75KW Gen Set

Hydraulically Deployed Anchors

Ballast System Capacity of 1950 CBM/hour

GOM

POR



1200 HP Tug

Posted on by

0


​VESSEL SPECIFICATION:

TYPE: MODEL BOW TUG
YEAR BUILT: 1998
LENGTH: 65′ OA
BREADTH: 22 OA
DEPTH: 8.5′ OA
VISIBILITY: 20′ OA

ENGINE SPECIFICATIONS:

RATED HORSEPOWER: 1200 HP
FREE RUNNING SPEED: 10 KNOTS
MAIN PROPULSION ENGINE: 2 CUMMINS NTA-14 M
REDUCTION: TWIN DISC – 516 – 5:1

CAPACITIES:

FUEL: 12,000 GALLONS
LUBRICANT: 5.5 DRUMS
POTABLE WATER: 6,400 GALLONS
QUARTERS: 4 BUNKS-FULL KITCHEN & BATH
CREW: 3

NOTE: “0” DISCHARGE CAPABILITIES

2100 HP Tugboat 80’s Build

Posted on by

0

Characteristics
Length, Overall

75 ft.

Beam

26 ft.

Depth

12 ft.

Maximum Draft

11 ft.

Deck Space

20 ft. x 24 ft.

Speed

10 Knots

Capacities

Fuel Oil

47,000 gal.

Potable Water

5,000 gal.

Lube Oil

450 gal.

 Machinery

Main Engines

(2) CAT 3412 TA

Horsepower

3,000 hp

Gears

Twin Disc MG 540, Red - 7:1

Generators

(2) GM 4-71 40KW

Steering

Electric / Hydraulic

Wheels

70" x 62"

Accomodations

Staterooms

3 / 5

Galley

Yes

A/C & Heating

Central

Tow & Anchor Handling

Winch

Smatco 48K Dbl Drum SBS

Line Pull

65,000 lbs.

Model

48 K - Dbl Drum - SBS

Capacity

2,100 ft. of 1 1/4 in.

Electronics

VHF

(1) Uniden Solara DSC, (1) ICOM IC-M302

SSB

Sea 322

Auto Pilot

ComNav 2001

Global Positioning

(2) Furuno GP 32

Radar(s)

(2) Furuno 1931

Depth Sounder

Sitex CVS-106LMKII

AIS

Furuno FA 150









Engine Alarms




Full Alarm








Welding Machine




Electric








Registration








Flag




United States








Home Port




New Orleans, LA









































2000 HP Tug in South America




			Posted on   by



0






















GENERAL INFORMATION:

LOA: 26.85 mts

Beam: 7.31 mts

Depth: 3.60 mts

Draft: Light 3.20 mts

Hull: Steel Gross Tons: 186.44

Net Tons: 126.37

Fuel Capacity: 21,288 Gal

Water Capacity: 10.000 Gal

Class: 40, 2-B-01-G, Seagoing, National Load Line

MACHINERY:


Main Engines (2) DETROIT 16V-149 @ 2000 HP Total

Gears: (2) TD-MG520 @ 7:1

Propellers: (2) Two S.S

Generators: (2) Two electric AC generator, 75KW at 1.200 RPM, driven by GM Detroit

Diesel, Model 671 fitted with day tank and Alarm.

Steering: Custom- Hydraulic: dual 15HP Racine Pumps; control valve, hydraulic oil

storage and surge tank.


Asking $375k















2300 HP Triple Screw Tug




			Posted on   by



0









Characteristics

Length, Overall 66.5 ft.

Beam 26 ft.

Depth10.5 ft.

Maximum Draft 9.5 ft.

Speed 10 Knots


Capacities

Fuel Oil33,600 gal.

Lube Oil450 gal.

Potable Water8,500 gal.


Machinery

Main Engines(3) CAT 3406E

Horsepower BHP1650

GearsTwin Disc MG 5161 – 7:1Kort NozzlesYes

Primary Generators(2) Cummins 6B 5.9G – 55KW


Tow & Anchor Handling

WinchSmatco 48-DPS-100Line Pull

100,000 lbs.Capacity2,400 ft. of 1 1/2 in.Single Drum


 AccomodationsStaterooms/Berths3/5Galley SeatingFully EquippedA/C & HeatingCentralPerformanceBollard Pull16 stElectronics

VHF3SSB1Auto Pilot1GPS2AIS1Radar(s)2Depth Sounder2Satellite Phone w/ email1Copy/Scanner/Printer1



















3600 HP Tugboat with Load Line




			Posted on   by










DSC00001


3600 HP  by (2) EMD 12-645-E2


Lufkin 5:1 Gears


118″x76″ Stainless 4 Blade Wheels


38.1m x 10.37m 4.88m


Draft 3.36/4.27


36 Ton Bollard Pull


Intercom 6940-1 Double Drum Winch with 315,000 lbs pull


Rebuilt 2012 Keel Laid at Main Iron Works in 1969


Location and Flag Columbia



















70′ Tripple Screw Model Bow




			Posted on   by










Horsepower: 3000 HP

Dimensions: 75’x26’x10.5′

Year Built: 2000s

Builder: A&B Industries

Main Engines: (3) CAT 3406E

Generators: (2) Cummins 55KW

Gears: Twin Disc MG 5161 7:1

Speed/Consumption: 10 Knots

Draft Loaded: 9.5

Water Capacity: 8500 usg

Fuel Capacity: 33,600 usg

Winches: SMATCO 48-DPS-100 Single Drum with 2,400

Fire Monitor

Location: GOM

POR
